Description
YXL15P
YXL 15-inch / 1-inch - 1000 Watts
The YXL cabinets use a single driver and 90 x 40 degree horn with 1-inch throat and 1-inch compression driver. Constructed from strong Polypropylene, YXL is poised to uphold Yorkville's reputation for reliability and durability. The cabinets can be positioned upright or used as a monitor wedge.
Designed as an all-purpose speaker with the Musician & DJ in mind, each YXL cabinet features 3 channels. The cabinet supports Bluetooth streaming and EQ pushbutton controls for Concert, Club & Monitor modes.
Features
- 1000 Watts (Peak) 500 Watts (Program)
- 15-inch woofer with 2.5-inch voice coil
- 3 Channels plus Master level
- 1-inch compression driver
- 90° x 40° HF dispersion
- Polypropylene cabinet construction
- Bluetooth streaming
- 3 performance modes (Concert, Club, Monitor)
Specifications
Specifications
- System Type Active Loudspeaker
- Active or Passive Active
- Power Rating (Watts) 500 Watts Program (1000 Watts Peak)
- Max SPL (dB) 127dB Continuous
- Frequency Response (Hz +/- 3dB) 45 - 16k (Hz +/-3dB)
- Dispersion (°H x °V) 90 x 40
- Crossover Frequency (Hz) 1.6kHz
- HF Horn Integrated into Baffle
- LF Driver(s) 15-inch (2.5-inch voice coil)
- LF Power Rating(Watts) 450 Watts Program (900 Watts Peak)
- HF Power Amplifier (Watts) 50 Watts Program (100 Watts Peak)
- HF Amplifier Type Class A/B
- LF Amplifier Type Class D
- Cooling Scheme Speed controlled fan
- Power Cable Yes
- Power Switch Yes
- Mixer Controls 3 recessed dial controls
- Level Controls x3 Chanels + Master
- EQ Controls Push button select, Concert, Club, Monitor
- Limiter Multiband excursion, RMS, rail
- Other Controls / Features 100 Hz HP with Sub, Mixer IN/OUT, Stereo/Mono out, 3.5mm Aux in, BT streaming
- Feet Rubber
- Bar Handles 2 x Side / 1 x Back
- Flying Hardware 2 (Top), 1 (Pullback)
- Optional Flying Hardware Yes
- Enclosure Materials Polypropylene, Metal grille
- Baffle Material Polypropylene
- Grille Powder Coated Steel with Grille Cloth
- Other Details Rubber feet on bottom and side with the monitor Wedge
- Dimensions (DWH xbackW, inches) 14.75 x 17 x 27.375
- Dimensions (DWH xbackW, cm) 37.5 x 43.18 x 70.4
- Weight (lbs/kg) 45 / 20.4
