Description
Coliseum Mini Series - C160W
Pot Light Ceiling Speaker
Ideal for any paging or background music system, the C160W is a 10-watt, 4-inch diameter flush mount-ceiling speaker designed specifically for quick and simple installation in office and retail environments.
Features
- 4-inch Flush Mount 'Pot Light' Ceiling Speaker
- 70-volt Operation
- Power Taps at 2.5, 5 and 10 Watts
- Closed Back Design
- Mounting Hardware Included
The C160W has built in 70-volt transformer and taps, and can operate at 2.5 watts, 5 or 10 watts. It also features an efficiency of 92dB (1 W/m) and a frequency response of 100 - 16kHz.
Rugged ABS plastic construction in a 'pot light' format with an all metal grille make the C160W ideal for any drywall or tile drop ceiling mount application. The C160W can be easily installed and driven by any 70-volt amplification system, including the Coliseum CA1 or CA1T.
Specifications
- System Type Pot Light Speaker
- Active or Passive Passive
- Program Power (Watts) 10
- Nominal Impedance (Ohms) 8 / 70 Volt Transformer
- Sensitivity (dB @1Watt/1m) 91
- Frequency Response (Hz +/- 3dB) 150 - 20k
- Driver Configuration Single 4 Inch
- 90 x 90
- Inputs - Screw Terminal Solder lugs
- Enclosure Materials ABS Plastic
- Grille Metal
- Dimensions (DWH xbackW, inches) 5.5 x 4.8
- Dimensions (DWH xbackW, cm) 14.2 x 12
- Weight (lbs/kg) 3 / 1.4
