Description
Amplifiers Series - PX1700
2 x 850 Watt Power Amplifier
Perfect for club or concert hall, the Yorkville PX Series PX1700 power amplifier delivers up to 1700 watts (2 x 850 watts @ 2 ohms). XLR and 1/4-inch inputs, binding post and Speakon™ outputs ensure the PX1700 can be integrated into virtually any high performance sound system or mobile PA.
Features
- Easily Drives Reactive Loads
- Delivers 1700 Watts Bridged Mono @ 4 ohms
- 850 Watts PRE Channel @ 2 ohms
- Efficient Front-to-Back Cooling Scheme
- Recessed Front Panel Gain Controls
- Advanced Protection Schemes
- Front Panel Power, Protect, Activity and Clip LED's
- Speakon™ and Binding Post Outputs
- Balanced XLR & ¼-inch TRS Inputs
- Sturdy All-Steel Construction
Specifications
- Amplifier class Class-H
- Continuous Average Power @ 8 Ohms BCD (Watts) 400
- Continuous Average Power @ 4 Ohms BCD (Watts) 600
- Continuous Average Power @ 2 Ohms BCD (Watts) 850
- Continuous Average Power Bridged BCD (Watts) 1700
- Burst Average Power @ 8 Ohms BCD(Watts) 600
- Burst Average Power @ 4 Ohms BCD (Watts) 1000
- Burst Average Power @ 2 Ohms BCD (Watts) 850
- Burst Average Power Bridged BCD (Watts) 1700
- Frequency Response (Hz, +/- 1dB) 30Hz to 20kHz
- Hum and Noise (un / Aweighted -dB) -100dB
- THD -1kHz- 4 OHMS 0.0003
- THD - 20Hz-20kHz, 4 Ohms 0.001
- Damping Factor (30 Hz - 400 Hz @ 8 Ohms) Greater than 300
- Crosstalk (1kHz / 20Hz-20kHz) -75dB / -60dB
- Input Impedance - Bal/Unbal (Ohms) 30kOhms/15kOhms
- Input Sensitivity (Vrms) For Full Power Out 1.4
- Max Voltage Gain (dB) 31dB
- Stereo / Mono / Bridge (S/M/B) Yes
- Protection DC/Load/Thermal
- Limiter Defeatable
- High Pass Filter No
- Cooling Fan
- Cooling Path Front to Back
- Inputs - XLR Yes (x2)
- Inputs - 1/4" Jacks Yes (x2)
- Outputs - Speakon 4-pin Yes
- Outputs - Binding Post Yes
- Power Consumption (typ/max) 700/1500
- Rack Spaces Two
- Transformer Type Toroidal
- Exterior Finish Black Paint
- Dimensions (DWH /D fm ears, inches) 16 x 19 x 3.5
- Dimensions (DWH /D fm ears, cm) 40.6 x 48.3 x 8.9
- Weight (lbs / kg) 35/16
