Universal Audio Teletronix LA-2A Classic Leveling Amplifier

(No reviews yet) Write a Review
SKU:
LA2A
UPC:
819937000034
Weight:
13.50 LBS
Shipping:
Calculated at Checkout
Availability:
Made to order! Call for Availability!
  • Universal Audio Teletronix LA-2A Classic Leveling Amplifier
  • Universal Audio Teletronix LA-2A Classic Leveling Amplifier
  • Universal Audio Teletronix LA-2A Classic Leveling Amplifier
$4,699.00

Description

True to the Original Design, our Famed Tube-Amplified T4 Electro-Optical Classic Compressor

Audio professionals revere the LA-2A. The original was immediately acknowledged for its smooth, natural compression characteristics. A unique tube-driven electro-optical attenuator system allows instantaneous gain reduction with no increase in harmonic distortion — an accomplishment at the time, still appreciated today. This faithful Universal Audio reissue marks the rebirth of the Teletronix LA-2A. Painstaking care has been taken to ensure that every new LA-2A provides the performance characteristics of the original. Each unit is point-to-point hand-wired and built in Scotts Valley, California, with every component carefully evaluated for authenticity. As a result, today’s LA-2A will bring the same legendary compression characteristics of the original to all of your recordings.

  • True to the original LA-2A in design, manufacturing and performance
  • Lag free, distortion free optical attenuator system
  • 10 milliseconds attack time
  • Hand-built in USA; backed by 1-Year limited warranty

Each unit is hand-built and hand-wired in-house at UA with each component being carefully evaluated for authenticity. No expense has been spared to guarantee that this LA-2A will bring that classic sound to your recording. Demand the original. Accept no copy.

Features

  • True to the original in design, manufacturing and performance
  • Lag free, distortion free optical attenuator system
  • Distortion less than 0.5% THD
  • 0 to 40 dB gain limiting
  • Balanced stereo interconnection
  • Frequency response 1 dB, 30 to 15,000 cps
  • Output level of 10 dBm and 40 dB gain
  • Low noise – less than 70 dB below ±10 dBm output
  • Hand-built in USA; backed by 1-Year limited warranty
View AllClose

Specifications

Input Impedance
50, 150, 250, 600 ohms

Output Load Impedance
50, 150, 250, 600 ohms

External Connections
Jones Barrier terminals and XLR connectors

Frequency Response
+0/-1 dB 30 Hz to 15kHz

Gain
40 dB å±1dB

Input Level
+16 dB maximum

Output Level
+10 dB nominal, +16 dB maximum

Distortion
Less than 0.5% THD (0.25% typical) at å±10 dBm

Noise
70 dB below +10 dBm output level

Attack Time
10 milliseconds

Release Time
0.06 seconds for 50% release; 0.5 to 5 seconds for complete release

Meter
dB gain reduction and dB output

Power Requirements
35 watts, 120/240 volts, 50/60 Hz

Environmental
Maximum operating temperature 160å¡F

Dimensions
19" Rackmount chassis, 3U

Weight
13 lbs.
