Sennheiser MEB 104 Installed boundary layer microphone

(No reviews yet) Write a Review
SKU:
MEB 104 B
UPC:
615104230224
Weight:
0.23 LBS
Shipping:
Calculated at Checkout
$229.00

Description

Compact and unobtrusively designed, the cardioid boundary layer microphone MEB 104 (cardioid) fits any style of interior and can be easily installed into surfaces such as tables or ceiling tiles. It features a proven Sennheiser microphone capsule for the best speech intelligibility, and is protected by a rugged housing. Its -L variant features a bi-color LED ring for status indication.

What's in the box?

  • MEB 104
  • Quickguide
  • Mounting material
View AllClose

Specifications

  • Connector
    • MEB 104: XLR-3, Pin assignment: 1 = gnd, 2 = +, 3 = −
    • MEB 104-L: XLR-5, Pin assignment: 1 = gnd, 2 = + (Mic +), 3 = −
    • (Mic −), 4 = LED green (trigger signal), 5 = LED red (default)
  • Current consumption
    • MEB 104: 3 mA
    • MEB 104-L: 6 mA
  • Colour black; white; nextel grey
  • Dimensions Height: 3.54 in (0.75 in above surface), Diameter: 1.12 in
  • Frequency response 40 Hz – 20 kHz
  • Max. sound pressure level 125 dB
  • Transducer principle pre-polarized condenser microphone
  • Weight 2.12 oz
  • Pick-up pattern cardioid
  • Nominal impedance 200 Ω
  • Phantom powering P 24 - P 48
  • Operating temperature 32 °to 104 ° F
  • Equivalent noise level 28 dB (A)
  • Equivalent noise level weighted as per CCIR 468-3 38 dB (CCIR)
  • Acoustics Boundary Layer Microphone
  • Dynamic range 97 dB (A)
  • Sensitivity 14 mV/Pa
  • Thread M 20
