Description
Blackmagic GPI & Tally Interface
GPI & Tally interface provides 8 contact closure inputs and 8 contact closure outputs for connecting to ATEM switchers and Videohub routers. Tallies will be displayed when connected to an ATEM switcher to indicate their "on-air" status and you can even connect multiple interfaces together to increase the number of inputs and outputs. GPI and Tally Interface also works as a Videohub control panel without buttons and LEDs so you can make your own! Now anyone can connect to Videohub routers to control cross-points!
Specifications
Connections
- Contact Closure
- 25 pin D-type connector providing 8 opto isolated inputs and 8 relay contact closure outputs.
- Computer Interface
- 1 x USB 2.0 high speed interface for configuration and firmware updates.
- Inputs
- Optical isolators triggered by connection to ground. Max 5V at 14mA.
- Outputs
- Mechanical relay contact closure to ground. Max 30V at 1A.
- Ethernet
- 10/100 BaseT with loop through for connecting to other ethernet enabled equipment.
Software
- Software Included
- Configured via ATEM Switcher Utility.
- Internal Software Upgrade
- Firmware built into software driver. Loaded at system startup or via updater software.
Operating Systems
- Mac 10.14 Mojave, Mac 10.15 Catalina or later.
- Windows 8.1 or Windows 10.
Power Requirements
- Power Supply
- 12V power supply included with international socket adaptors for all countries.
Physical Specifications
- Weight: 0.26 lbs
- Width x Height x Depth: 3.54 x 0.91 x 3.78"
Environmental Specifications
- Operating Temperature
- 0° to 40° C (32° to 104° F)
- Storage Temperature
- -20 - 60 degrees celsius
- Relative Humidity
- Up to 95%
What's Included
- GPI and Tally Interface
- Software CD
- Power Supply
Warranty
12 Months Limited Manufacturer's Warranty
