BAE 312A - 500 Series Mic Pre

(No reviews yet) Write a Review
SKU:
312AMOD
Availability:
Usually ships within 24 hours
Weight:
2.00 LBS
Shipping:
Calculated at Checkout
$790.00

Description

312A Features

The 312A is available as a 500 series module or a single or dual channel 19" rackmount.

Because there are no capacitors in the audio path, the 312A is super fast and punchy, allowing transients to pass easily, making them a favourite for drummers.

Made with the highest quality parts including Jensen input and output transformers and the Avedis® 1122 opamp. The 312A also includes a high impedance DI for instruments.

  • Made using Avedis® 1122 opamps
  • Supplied with Jensen input and output transformers.
  • Switches have gold contacts for long life.
  • High impedance direct input for guitar and synthesizer.
  • Separate front panel switches for phantom power.
View AllClose

Specifications

Frequency Response
5Hz to 75kHz (-3dB)

Mic Input Impedance
≈1400 ohms

Line Input Impedance
10k ohms

DI Input Impedance
≈250k ohms

Output Impedance
75 ohms

Common Mode Rejection Ratio
110dB min @ 60Hz

Maximum Output Level
+27.1 dBu @ 600Ω

Power Requirements
115/230 VAC, 27W (Rackmount)
40mA per Rail (Module)

Gain dB
10 to 66 dB

Equivalent Input Noise
-120 dBu; Unweighted 300kHz Bandwidth

View AllClose
