Description
The Shure PA805 is a directional antenna for increased range and reduced interference as compared to omnidirectional 1/2-wave antennas.
The PA805 can be mounted on a microphone stand or mounted to a wall using the integral swivel adapter bracket.
NOTE: Using too many transmission antennas in one installation can reduce performance. To combine PSM antennas, use a PA821A Antenna Combiner.
Specifications
Model
PA805SWB
- RF Frequency Range (MHz): 470-952
- Dimensions(with mounting accessories): 334 mm H, 378 mm W, 27.9 mm D
(13.15 in. H, 14.88 in. W, 1.10 in. D) - Net Weight (without cable): 11.3 oz (319 grams)
PA805X
- RF Frequency Range (MHz): 944-952
- Dimensions(with mounting accessories): 944-952 226 mm H, 234 mm W, 27,9 mm D
(8.90 in. H, 9.21 in. W, 1.10 D in.) - Net Weight (without cable): 8 oz. (227 grams)
- Antenna Gain
- PA805X = 6dBi Typical
- PA805SWB = 6.5dBi Typical
- 3 dB Beam Width: 100 degrees
- Radiation Pattern: Directional; Cardioid
- Connector: 50 W, Female, BNC-type
- Swivel Adapter
- Positive-action, break resistant, adjustable from 0 to 90 degrees, with standard 5/8 in. -27 thread
- OPTIONAL ACCESSORIES
- 7.6 m (25ft) Antenna Extension Cable...........................UA825
- 15.2 m (50ft) Antenna Extension Cable.........................UA850
- PSM Antenna Combiner................................................PA821
