Description
P10T
Wireless Transmitter
Shure’s P10T is a networkable, full-rack, dual-channel wireless transmitter used in conjunction with the P10R Wireless Bodypack Receiver as part of the PSM® 1000 Personal Monitor System. The P10T Wireless Transmitter combines state-of-the-art technology with touring-grade features for professional monitoring applications of any size with no room for error. It offers a 72 MHz to 80 MHz tuning bandwidth, networked remote control via Wireless Workbench® software, advanced rechargeability options, and PSM® 900 backwards compatibility.
FEATURES
- Touring-Grade Design and Performance
- Full-rack, dual-channel wireless transmitter in an all-metal chassis provides touring-grade performance
- Networked control via Ethernet connection vastly simplifies setup for high channel counts and enables remote control via Wireless Workbench software
- Internal power supply with IEC in/out ports enables easy power chaining in the rack
- Robust RF Performance and Networked Control
- Up to 80 MHz tuning bandwidth provides flexibility in today’s crowded and unpredictable RF environments
- Exceptional transmitter linearity vastly reduces frequency intermodulation and allows up to 39 compatible channels per frequency range
- Networked frequency coordination simplifies setup for high channel counts.
- IR sync enables you to send the identified frequencies and spectrum plot to the P10T transmitter directly
- Ethernet connectivity facilitates the programming of compatible frequency assignments from one transmitter to every other P10T transmitter on the network for vastly simplified and streamlined setup
- Spectrum display provides a front-panel spectrum plot with selectable zoom
- Advanced Setup and Operation
- Full compatibility with Wireless Workbench and ShurePlus™ Channels software provides advanced RF spectrum plotting, comprehensive frequency coordination, and live monitoring and adjustment of transmitter settings, including:
- RF mute enable/disable
- RF output power adjustments
- Aux/line level
- Audio input level
- Channel/device name edit
- Exceptional Audio Quality
- Patented Audio Reference Companding offers natural and transparent sound
Specifications
- Input 100–240 V AC, 50/60 Hz, 0.5
A max. (5.5, with outletloaded) - Output 100–240 V AC, 50/60 Hz, 5 A
max., unswitched
- Connector Type: Combination XLR and 6.35 mm (1/4") TRS
- XLR Non-inverting (pin 2 positive with respect to pin 3)
- 6.35 mm (1/4") TRS Tip positive with respect to ring
- +4 dBu +29.2 dBu
- -10 dBV +12.2 dBu
- XLR 1=ground, 2=hot, 3=cold
- 6.35 mm (1/4") TRS Tip=hot, Ring=cold,
- Sleeve=ground
- Connector Type: 6.35 mm (1/4") TRS
- Configuration: Electronically balanced
- Impedance: Connected directly to inputs
