Description
AD1 delivers impeccable audio quality and RF performance with wide-tuning, High Density mode, and encryption. Features durable metal construction, optional rechargeable power with dockable charging, and TA4 and LEMO3 connector options.
The AD1 is a wireless bodypack transmitter compatible with Axient Digital Wireless Systems.
With breakthrough RF performance and wide tuning up to 184 MHz, the AD1 puts professional-quality wireless digital audio within reach.
Features
- Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage
- Encryption-enabled, secure transmission
- Two connector options: TA4 and LEMO3
- Detachable ¼-wave antenna
- AA or SB900A lithium-ion rechargeable batteries for convenient power options
- External contacts for docked charging
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
Specifications
- Gain Offset Range –12 to 21 dB (in 1 dB steps)
- Battery Type Shure SB900A Rechargeable Li-Ion or LR6 AA batteries 1.5 V
- Battery Runtime @ 10 mW
- Shure SB900A: up to 9 hours
- Alkaline: up to 8 hours
- Dimensions 86 mm × 66 mm × 23 mm (3.4 in. × 2.6 in. × 0.9 in.) H × W × D
- Weight 155 g (5.47 oz.), without batteries
- Housing Cast Aluminum
Audio Input
- Connector
- 4-Pin male mini connector (TA4M)
- LEM03 connector
- Configuration: Unbalanced
- Impedance: 1 MΩ
- Maximum Input Level
1 kHz at 1% THD - Pad Off: 8.5 dBV (7.5 Vpp)
- Pad On: 20.5 dBV (30 Vpp)
- Preamplifier Equivalent Input Noise (EIN)
System Gain Setting ≥ +20 - –120 dBV, A-weighted, typical
RF Output
- Connector SMA
- Antenna Type 1/4 wave
- Impedance 50 Ω
- Occupied Bandwidth <200 kHz
- Modulation Type Shure Axient Digital Proprietary
- Power 2 mW, 10 mW, 35 mW
