Description
Motu MicroBook IIc Studio-Grade Audio Interface for Personal Recording
The MicroBook IIc turns your Mac, PC or iPad into a 4 x 6 recording studio with all the audio I/O and mixing you need to make pro-quality recordings.
Plug in your mic, guitar, and keyboard and record up to four analog inputs simultaneously. Mix using CueMix FX software and apply DSP-powered multi-band EQ and compression. Listen to everything on headphones or studio monitors.
From initial inspiration to polished track, the MicroBook IIc gets you there with broad compatibility, bus-powered convenience and professional quality.
Features
- 4-input, 6-output bus-powered USB audio interface for Mac and Windows.
- Supports Apple® iPad® with camera connection kit (sold separately).
- 6-bus digital mixer to route and mix live inputs with audio software tracks.
- Mic input with Precision Digital Trim™, 48V phantom power, and 20 dB pad.
- Guitar input with Precision Digital Trim.
- Stereo line input (1/4-inch or stereo mini).
- Stereo 1/4-inch balanced main outs, plus 1/8-inch mini line-level out.
- S/PDIF digital out at rates up to 96 kHz.
- Multi-band EQ, compressor, and test tone/noise generator.
- Instrument tuner and analysis tools, including FFT display and oscilloscope.
- Includes AudioDesk DAW software for Mac and Windows, a USB cable, and a power adapter
Specifications
- Converters 24-bit
- Sample Rates 44.1, 48, 88.2, 96kHz
- Analog In 1 x XLR mic input with preamp
- 1 x 1/4" hi-Z guitar
- 2 x 1/4" TRS phone (balanced/unbalanced)
- 1 x 1/8" stereo "mini" (unbalanced)
- Analog Outputs 2 x 1/4" balanced TRS main out
- 1 x 1/8" stereo "mini" line out (unbalanced)
- 1 x 1/4" TRS headphone
- Digital Input - none -
- Digital Output 1 x RCA coaxial S/PDIF
- Computer I/O 1 x USB 2.0 "High-speed"
- Sync Out S/PDIF
- Headphone Output 1 x 1/4" TRS phone with volume control
- Phantom Power +48V
- Power Supply 1 x Micro-B USB
- Top panel 2 x 3-segment ladder LEDs • main outs
- 1 x 4-segment LEDs • mic in
- 1 x 4-segment LEDs • guitar in
- 1 x 3-segment LEDs • line in
- 1 x 3-segment LEDs • line out
- 1 x LED • 48V phantom power
- 1 x LED • -20 dB pad
- 2 x LEDs • main/phone vol
- 1 x digital rotary encoder • mic trim
- 1 x digital rotary encoder • main/phone volume
- Power Specifications USB bus power (computer)
- USB-to-AC power adapter (iPad)
- (USB cable and AC wall adapter included)
- Dimensions
- Length: 5 ½ in / 14 cm
- Width: 3 ⅝ in / 9.2 cm
- Height: 1 ¼ in / 3.2 cm
- Mac System Requirements
- Intel Core i3 Mac or faster (including the new Apple silicon Macs*)
- 4 GB RAM or more
- Mac OS X version 10.6.8 or later
- Available high-speed USB 2.0 port
- A large hard drive (preferably at least 250 GB)
- *Apple Silicon devices require adjustments to security settings. See this tech note for more information.
- Windows System Requirements
- Pentium 4 CPU (or equivalent) 1 GHz or faster
- 4 GB RAM or more
- Windows 10, 8, or 7*
- Available high-speed USB 2.0 port
- A large hard drive (preferably at least 250 GB)
- iOS Requirements
- iOS 7 or later
- Included software
- CueMix FX
- AudioDesk
- Operating Systems
- Mac OS X version 10.11, 10.10, 10.9, 10.8, 10.7, 10.6 (10.6.8 or later required)
- Windows 10, 8, or 7*
- 64-bit operation
- Available for Mac OS X version 10.6.8 or later
- Available for 64-bit versions of Windows 7* (or later)
- Requires a 64-bit CPU (and host application for plug-in versions)
