Magmatic PM-DMX1

(No reviews yet) Write a Review
SKU:
PMD003
UPC:
810008263044
Weight:
5.00 LBS
Shipping:
Calculated at Checkout
$430.00

Description

PM-DMX1

Magmatic PM-DMX1™ is an optional pan motor accessory for the Magmatic Crisp Max™ Snow Machine. Install the output nozzle of the Crisp Max, using the included mounting bracket, onto the PM-DMX1 to precisely control 120 degrees of pan movement via DMX-512 or manually using the 4-button LED control panel menu display on the unit. The PM-DMX1 features 2 DMX channel modes, 0-120 degree position index movement and 3 different degree internal auto-pan programs (60°, 90°, 120°) each having 5 speed settings, a pan inversion mode which inverts the pan movement, primary / secondary modes, 5pin DMX in/out for easy control connection and linking multiple units, an included mounting bracket that better balances weight distribution of the Crisp Max nozzle unit, mini-omega bracket so PM-DMX1 can be clamped and /truss mounted, and a 100-240V auto switching power supply.

Features

  • 120 Degrees of Pan Movement
  • Manual and DMX-512 Control
  • 2 DMX Channel Modes
  • Primary/Secondary Modes
  • 60°, 90°, 120° Auto-Pan Programs
  • 5 Auto-Pan Program Speeds
  • Pan Inversion Mode
  • Holds up to 35lbs.
  • Includes Mounting Bracket for Crisp Max Nozzle
  • Includes Omega Bracket for clamp / truss mounting
View AllClose

Specifications

CONTROL / CONNECTIONS

  • Manual and DMX-512 (2 channel modes)
  • 0-120° Pan Movement
  • Pan Inversion Mode
  • Primary/Secondary Mode
  • Auto-Pan Programs and Varying Speeds
  • 4-Button Control Panel
  • LED System Menu Display
  • 5pin DMX In/Out
  • AC Power Plug

SIZE / WEIGHT

  • Length: 6.3” (159.0mm)
  • Width: 5.8” (147.0mm)
  • Vertical Height w/ Bracket: 13.0” (330.5mm)
  • Weight w/ Bracket: 5.0 lbs. (2.28kg)

ELECTRICAL

  • AC 100-240V 50/60Hz
  • 11W Max Power Consumption

APPROVALS / RATINGS

  • CE | IP20 | cETL
