JBL SRX815 15" Two-Way Bass Reflex Passive System

(No reviews yet) Write a Review
SKU:
SRX815
UPC:
691991001635
Weight:
67.00 LBS
Shipping:
Calculated at Checkout
Availability:
Usually ships within 24 hours.
  • JBL SRX815 15" Two-Way Bass Reflex Passive System
  • JBL SRX815 15" Two-Way Bass Reflex Passive System - No Grille
  • JBL SRX815 15" Two-Way Bass Reflex Passive System - Monitor
  • JBL SRX815 15" Two-Way Bass Reflex Passive System - Handle
  • JBL SRX815 15" Two-Way Bass Reflex Passive System - Back
$1,389.00

Description

15" Two-Way Bass Reflex Passive System
SRX815 is a two-way full range speaker with a 15” woofer made for use as a light to medium duty main PA, monitor, or rear or side fill. Featuring M10 suspension points and feet for both floor standing and monitor use, the SRX815 is an ideal solution for musicians, bands, and DJs, concert use, public speaking, or installations such as performance venues, corporate spaces, educational facilities or houses of worship.Tunings and presets are available for Crown ITech HD and XTI 2 amps as well as dbx VENU360 signal processors.

Features

  • Premium JBL Transducers
  • Rugged, versatile enclosures
  • Tunings available for Crown amps and dbx signal processors
  • Fully supported in Audio Architect
  • Power Handling: 3200W Peak, 1600W Program, 800W Continuous
  • Frequency Range: 41Hz-20kHz
  • Frequency Response: 56Hz-20kHz
  • Max SPL: 136dB
  • Coverage Pattern: 90 x 50
  • Amplification options: Passive/Bi-Amp

Technology

PURPOSEFUL DESIGN
Every detail in the SRX800 Series was purposefully designed and thought through with full consideration for its intended use. Ergonomically designed handles support an easy, non-fatiguing grip for streamlined handling. M10 suspension points, indexed feet, and pole/tripod mounts support a wide, flexible array of configurations.

TRANSDUCER TECHNOLOGY
JBL’s patented Differential Drive® Technology ferrite drivers incorporate 3" voice coils with lower mass ferrite magnets for reduced weight, increased power handling, exceptionally low distortion and extended low frequency response. JBL’s 2432H is the only neodymium 3" voice coil compression driver in this class, delivering very high power levels and smooth, crystal clear sound.

Applications

  • Live performance systems.
  • Mobile and fixed DJ systems.
  • Sound system rental and tour.
  • Permanent installations.
View AllClose

Specifications

System Type: Passive 15”, two-way, bass-reflex
Maximum SPL Output: 136dB
Frequency Range (-10dB): 41hz - 20khz
Frequency Response (- 3dB): 56hz - 20khz
Sensitivity (1W/1m): 95dB
System Power Rating: 3200W Peak, 1600W Program, 800W Continuous
Nominal Impedance: 8 Ohm
Connectors: NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable)
Operational Modes: Passive/Bi-Amp
LF Driver: 2275H
HF Driver: 2432H
Coverage Pattern: 90 x 50
Crossover Frequency: 1.9khz
Enclosure Material: 18mm plywood
Monitor Angle: 50°
Suspension/Mounting: Dual 36mm pole socket, 12 x M10 Suspension points
Handles: 3
Finish: Obsidian Duraflex™ finish
Grille: Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
Dimensions (L x W x H): 18.82" x 18.03" x 27.20" (478mm x 458mm x 691mm)
Weight: 57.0 lbs (25.9kg)
Shipping Weight: 67.0 lbs (30.4kg)
