Description
Dual 8" 2-Way Loudspeaker System featuring CWT Crossfired Waveguide Technology
The JBL Crossfired Waveguide Technology CWT128 is a compact full-range 2-way system designed to provide extremely wide-angle coverage with maximum bandwidth and SPL in a single system package. The unique wide coverage pattern horn is designed to provide seamless coverage to 160-degrees horizontally. CWT128’s small footprint makes the system ideal for nearly all architecturally sensitive environments, taking up about a third of the footprint of two speakers splayed side by side.
FEATURES
- Seamless horizontal coverage across a full 160°
- Compact size and small footprint make it ideal for architecturally sensitive environments
- Dual 205 mm (8 in) LF transducers
- Extremely wide-coverage 160° x 60° waveguide
- Dual 25 mm (1") exit, 38 mm (1.5") diaphragm compression driver
- Easy to install with 4 M10 attachment points built in across the top and sides
- 4 M8 points on the back panel accept OmniMount® wall mounting brackets
- WRC and WRX weather resistant versions are available upon request
- CWT128 is available in white - WH
Specifications
TECHNOLOGY
- Crossfired Waveguide Technology (CWT)
- At the heart of the CWT128 is the CWT Waveguide featuring a wide coverage pattern designed to provide seamless horizontal coverage across a full 160°. Based on JBL patented technology, the CWT Waveguide is essentially split in half and loaded with two compression drivers facing in different directions.
- Proven Dual 2408H-1 Compression Drivers
- High frequencies are handled by dual 2408H-1 1" exit, 1.5" diaphragm neodymium compression drivers that deliver higher power levels with lower distortion, better coverage and lighter weight. These proven JBL drivers are renowned for their high power handling and smooth response.
- High Performance 8" JBL SFG™ Low Frequency Drivers
- Low frequencies are handled by dual 8" JBL SFG™ (Symmetrical Field Geometry) LF drivers each with a copper clad aluminum edge wound 2.5" voice coil and a copper clad pole piece that improves performance by reducing voice coil inductance and distortion. The SFG LF drivers combine smooth response, extended low frequency bandwidth, and extremely low distortion. Delivering an optimum balance of efficiency and bass response, they perfectly complement the CWT Technology.
APPLICATIONS
- Transportation Facilities
- Cinema
- Sports Facilities
- Theme Parks
SPECIFICATIONS
- System Format Extremely Wide Angle Coverage Dual 8" 2-Way Loudspeaker System
- Frequency Range (-10 dB) 71 Hz - 20 kHz
- Frequency Response (+/-3 dB) 96 Hz - 19 kHz
- Coverage Pattern 160° x 60°
- System Sensitivity 94 dB SPL/1W/1m
- Rated Maximum SPL (1m) 129 dB
- System Nominal Impedance 8 Ohms
- Long-Term System Power Rating 450W (1800W Peak)
- System Power Rating 850W/1700W/3400W Continuous/Program/Peak
- Crossover 1.5 kHz
- Low Frequency Driver 2 x JBL 228J, 205 mm (8 in) SFG™ driver with 64 mm (2.5 in) edge wound voice coil
- High Frequency Driver 2 x 2408H-1 25 mm (1 in) exit compression driver, 38 mm (1.5 in) voice coil
- High-Frequency Waveguide Crossfired Waveguide
- Finish Black DuraFlex™ finish. White (-WH) available upon request
- Dimensions (W x H x D) 811.28 x 259.59 x 300.74 mm (31.94 x 10.22 x 11.84 in)
- Weight 18.6 kg (40.9 lb)
