Description
CST-2120
The rack-mountable JBL CST-2120 transformer module provides impedance and voltage matching for the CSA-2120 amplifier to drive 70V and 100V distributed speaker systems.
Features
- Providing two channels for constant voltage operation
- 70V/100V Outputs
- Rack-mountable with CSA2120
- Detachable block input and output connectors
Specifications
- Max Input Power 120W/Ch
- Max Input Voltage 32Vrms
- Insertion Loss Less than 1dB
- Frequency Response +/-1 dB @ 70Hz - 15kHz
- Dimensions 8.2" x 1.7" x 7" (209 mm x 44 mm x 178 mm)
