Description
The Furman M-8x AR Voltage Regulator is intended to protect sensitive electronic equipment from problems caused by AC line voltage irregularities such as brownouts, sags, and over-voltage conditions. Such irregularities can cause audio tonal changes, digital equipment malfunctions (such as loss of MIDI programs or other data), or in extreme cases, permanent damage.
Features
- Provides nine regulated, conditioned AC outlets-eight on the rear panel and one on the front
- Input capacity is 15 A; output capacity is 12 to 15 A
- Extreme over-voltage (instant) shutdown and under-voltage (delayed) shutdown, safeguard connected equipment
- Extreme Voltage Shutdown (EVS) indicator LED
- Extreme over-current shutdown protects regulator and connected equipment.
- Extreme Current Shutdown (ECS) indicator LED
- Tri-color “In-Regulation” indicator
- Protection OK indicator
- Eight element, Bi-color bar graph meter to indicate input line voltage
- User accessible thermal circuit breaker protects against overload
- Low noise toroidal autotransformer with very low stray magnetic field leakage
- Front Panel ON/OFF switch
- Compact, lightweight unit weighs only 15 lbs. (6.8 kg)
Suitable For
- Professional Audio
- Recording
- DJ Equipment
- Instrument rigs
Specifications
Nominal input voltage 120 VAC 50/60Hz
Regulation capture range 97 VAC to 141 VAC
Output Voltage 120 VAC ±5V
Output Current Rating 15 Amps for input voltages of 124V
Output Current De-rating 113 mA per volt to a minimum of 12.3A at 100V
Voltage Shutdown Range Less than 75V or greater than 145V
ECS Shutdown Range Within 10 cycles at 100A, and within 1 cycle for currents greater than 200A
Voltmeter Accuracy ±5 VAC
Spike Protection Modes L-N
Spike Clamping Voltage TVSS rating of 400 volts peak at 500 A, L-N (tested to UL-1449 3rd Ed.)
Response time 1 nanosecond
Maximum surge current 15,000 Amps
Maximum spike energy 225 joules
Noise attenuation Transverse: -16dB @ 10KHz, -33dB @ 100 kHz, -48dB @ 400KHz
Safety Listing cCSAus
EMI FCC Part 15 Class B
Warranty 3 Year Limited
