Elation Prisma Par 20 UV Wash

(No reviews yet) Write a Review
SKU:
PSP020
UPC:
810008261149
Weight:
8.00 LBS
Shipping:
Calculated at Checkout
  • Elation Prisma Par 20 UV Wash
  • Elation Prisma Par 20 UV Wash
  • Elation Prisma Par 20 UV Wash
  • Elation Prisma Par 20 UV Wash
  • Elation Prisma Par 20 UV Wash
$547.00

Description

PRISMA PAR 20

PRISMA PAR 20™ is an exterior IP65 rated UV wash par luminaire that produces 365nm peak true UV output with zero visible light. Features include a 20 degree narrow beam angle, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control, dual adjustable mounting yokes, a durable aluminum housing, IP65 DMX 5pin XLR and locking power in/out connections.

Features

  • IP65 Rated Exterior High-Power UV Wash Par Luminaire
  • 20 Degree Narrow Beam Angle
  • 365nm Peak True UV Wavelength
  • Zero Visible Light Output
View AllClose

Specifications

SOURCE

  • (12) 2W High Power UV Diode LEDs
  • 20,000 Hour Average LED Life*

*Test lab conditions. May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA

  • 20 Degree Narrow Beam Angle
  • 365nm True UV Peak Wavelength

EFFECTS

  • High Speed Electronic Strobe
  • Variable Dimming Curve Modes

CONSTRUCTION

  • Rugged IP65 Rated Housing
  • Dual Adjustable Mounting Yokes

CONTROL

  • Multiple DMX Channel Modes
  • Onboard 4 Button Touch Control Panel
  • DMX-512 and RDM Protocol Support

CONNECTIONS

  • Locking 5pin XLR Connector In/Out
  • IP65 Locking Power Connector In
  • With Wired Digital Communication Network

SIZE / WEIGHT

  • Length: 8.58 in. (218mm)
  • Width: 5.90 in. (150.6mm)
  • Vertical Height: 9.72 in. (246.6mm)
  • Weight: 5.29 lbs. (2.40kg)

ELECTRICAL

  • AC100-240V 50-60Hz
  • 27W Max Power Consumption

THERMAL

  • 14°F to 113°F (-10°C to 45°C)
  • Air Cooled

APPROVALS / RATINGS

  • CE | cETLus | IP65
