Description
Prisma Driver 8 IP
PRISMA DRIVER 8 IP™ is an easy to use 48VDC, IP65 protected, driver system which provides individual DMX-512 control including variable delayed time dimming modes for up to (8) PRISMA MINI UV LED series fixtures including the PRISMA MINI PAR 20™, PRISMA MINI PAR 45™ and the PRISMA MINI BAR 20™.
Features
Features include a rugged IP65 housing, easy keyhole slots for wall and surface mounting, multiple DMX control modes, an onboard 4 button touch control panel, 8x 4pin locking output sockets, DMX 5pin locking XLR in/out and locking power in/out.
Specifications
CONSTRUCTION
- Rugged IP65 Housing
- Easy Keyhole Slots for Wall/Surface Mounting
CONTROL
- Multiple DMX Channel Modes
- Onboard 4 Button Touch Control Panel
- DMX-512 and RDM Protocol Support
CONNECTIONS
- 8x 4pin locking output sockets (8 PRISMA MINI fixtures max)
- Locking 5pin XLR Connector In/Out
- IP65 Locking Power Connector In/Out
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 4.05 in. (102.9mm)
- Width: 10.4 in. (264.3mm)
- Height: 8.74 in. (221.9mm)
- Weight: 8.05 lbs. (3.65 kg)
ELECTRICAL
- AC90-240V, 50-60Hz
- 48VDC 8.3A
- 167W Max Power Consumption
THERMAL
- Maximum Temperature (Ambient): 113° F (45° C)
- Minimum Temperature (Ambient): 14° F (-10° C)
APPROVALS / RATINGS
- CE | cETLus *Pending | IP65
