Dynaudio Professional LYD 7 Nearfield Monitor

(No reviews yet) Write a Review
SKU:
LYD-7
UPC:
5706937616783
Weight:
17.65 LBS
Shipping:
Calculated at Checkout
Availability:
Usually ships within 24 hours.
  • Dynaudio Professional LYD 7 - Angled View
  • Dynaudio Professional LYD 7 - Front
  • Dynaudio Professional LYD 7 Nearfield Monitor
  • Dynaudio Professional LYD 7 - Back
  • Dynaudio Professional LYD 7 Nearfield Monitor - Back Panel
$649.00

Description

LYD 7
The latest edition to our Professional monitors - LYD - redefines power and precision
LYD excels at low volume precision making them perfect for the smaller setups, edit rooms, and home studios.
Each drive unit is handcrafted in our factory in Skanderborg, Denmark using our soft-dome tweeters and MSP woofers to ensure an ideal sound dispersion.

Introduction

The new LYD 7 uses advanced Digital Signal Processing to extend or curtail the low-frequency response by 10 Hz where need while both Position and Sound Balance ensure better performance in any environment.
Compared to its smaller sized sibling, the LYD 7's larger woofer helps extends bass response.
A ferrit magnet system with vented pole piece for accurate driver control. Large diameter voice coil surrounds the magnet for superior linearity. The aluminium voice coil and wire are low mass so its transient response is quick and accurate. To ensure the ideal mix between stiffness, weight, and dampening for unrivalled accuracy, we mould the diaphragm and dust cap in one piece with our proprietary Magnesium Silicate Polymer.

Features

  • Nearfield monitor with 7'' woofer
  • Max. SPL (1m, pair): 109dB
  • Crossover freq.: 4300 Hz
  • Freq. Response of 45Hz - 22kHz
  • HF 50W/LF 50W Class-D amplification
  • Bass Extension
  • Position switch
  • Sound Balance

Design Principles
Dynaudio monitors are designed to speak the truth so you get exactly what you need: an exact reproduction of your mix. Great mixing derives from attention to detail while striving for a final mix that goes way beyond the sum of its parts. We believe that the same principle applies when designing ultimate monitors.
Utmost care in selection of materials and production combined with the industry's most thorough and extensive testing program allow our monitors to achieve 100 percent consistency - not just between different pairs, but also when crossing pairs or relying on pairs in different locations.
And due to our unique driver technology our monitors are neutral and uncolored. The smooth clarity in combination with the outstanding dynamic capabilities of our monitors ensure that you can work long hours without ear fatigue.

View AllClose

Specifications

Sensitivity (85dB @ 1m, free field)
+6dB setting: 50 mV
0dB setting: 100 mV
-6dB setting: 200 mV

Cut-off frequencies -6db limits
Bass Extension +10: Hz 65 Hz - 21 KHz
Bass Extension 0 Hz: 55 Hz - 21 KHz
Bass Extension -10 Hz: 45 Hz - 21 KHz
Free field frequency response (+/- 2dB, -10 Hz Bass Extension): 55 - 19 kHz

Maximum SPL
Per pair @ 1m in half space: 109 dB
Crossover Frequency: 4.3 kHz

Speaker
Tweeter: 28 mm Soft Dome
Woofer: 7" MSP
Connections: XLR & RCA analog input
Dimensions: 186 x 320 x 296 mm
Weight: 8 kg

Amplifier
Power (Tweeter/Woofer): 50/50 W
Power Consumption Standby: <0.5 W
Power Consumption Max.: 100 W
Input voltage: 90 - 230 V AC, 50 - 60 Hz
