Description
The Soundweb London Analog Output Card is designed to populate any of the four card slots on Soundweb London BLU-800, BLU-805, BLU-806, BLU-320, BLU-325, BLU-326, BLU-160, BLU-120, BLU-80, BLU-32 and BLU-16 devices. This analog card enables Soundweb London devices to send line level signals.
The Analog Output Card has two Combicon connectors which are used as follows:
Connector 1
- Balanced / Unbalanced Audio, Channel 1 - Mic/Line
- Balanced / Unbalanced Audio, Channel 2 - Mic/Line
Connector 2
- Balanced / Unbalanced Audio, Channel 3 - Mic/Line
- Balanced / Unbalanced Audio, Channel 4 - Mic/Line
Specifications
Connector 1 [Line Combicon]
- Signal 4 3
- Pin [S + -] [S + -]
Connector 2 [Line Combicon]
- Signal 2 1
- Pin [S + -] [S + -]
Balanced
- Hot: to +
- Cold: to –
- Shield: to S
Unbalanced
- Hot: to +
- Link to Shield: to –
- Shield: to S
Technical Specifications
Analog Outputs: Up to 4 electronically balanced on Phoenix/Combicon removable screw connectors
Maximum Output Level: +19dBu
Output Impedance: 40 Ohms balanced, 20 Ohms unbalanced
Frequency Response: 20Hz-20KHz (+0.5dB/-1dB)
THD: <0.01% 20Hz to 20KHz, +10dBu output
Dynamic Range: 108dB typical, 22Hz-22KHz unweighted
Crosstalk: <-75dB
D/A Latency: 28/Fs [0.58ms@48k, 0.29ms@96k]
