Description
Just as every AxC card within the Audio ToolBox range, the AxC-ES100 can equally be used in AVBx3 or AVBx7 platforms.
Using one slot of either ToolBox, the AxC-ES100 allows you to bring both EtherSound and ASIO interfaces into your network configuration.
Key features
- Using only one Audio ToolBox slot, the AxC-ES100 can be used either with AVBx3 or AVBx7 platforms
- 64 inputs and 64 outputs
- One RS232 port compatible with Yamaha HA remote
- ASIO through the third port (up to 64 channels in and 64 channels out)
- Remote management with AVS-Monitor software
- Two EtherCon connectors allowing 64 channels extraction and 64 channels insertion to ES100 network
Specifications
- Size 200 mm x 100 mm x 40 mm –AuviTran Audio ToolBox platform cards format
- Power Supply +12V / +3.3V - Through AuviTran Audio ToolBox backplane
- Storage Temp/Humidity: - 5°C to 70°C / 0% to 95% (non-condensing)
- Operating Temp/Humidity: 0 °C to 50°C / 5% to 90% (non-condensing)
- Connectors 2 x Neutrik EtherCon RJ45-XLR female connectors (EtherSound ES100 from/to links), 1 x RJ45 connector for third port (PC control and ASIO Streamer interface), 1 x Sub-D9 (RS232) serial interface
- Audio Outputs 64 channels extracted from any of the 64 EtherSound downstream channels or from any of the 64 EtherSound upstream channels in bidirectional mode @ 44.1 kHz or 48kHz
- Audio inputs 64 channels inserted from any of the 64 EtherSound downstream channels or from any of the 64 EtherSound upstream channels in bidirectional mode @ 44.1 kHz or 48kHz
- Sample format 24 bit
- Sample rate 44.1 kHz, 48kHz, 88,2 kHz, and 96 kHz
- Synchronization Automatic from EtherSound network
ASIO
- I/O count Up to 64 ASIO inputs and 64 ASIO outputs from/to EtherSound
- Sample format 24 bit
- Sample rate 44.1 kHz, 48kHz, 88,2 kHz, and 96 kHz
Host PC minimum specifications
- Operating system Windows 8/Seven/Vista/XP for 32 or 64 bit versions (XP not recommended for ASIO due to its poor NDIS priority management)
- Processor / Memory Dual core CPU, clock speed > 2GHz + At least 2 GB for Windows 8, 7 or Vista
- Network 100Mbits full duplex Ethernet adapter with latest NDIS driver (Performances of the ASIO driver are directly related to NIC driver)
- Storage 7200rpm disk or better for ASIO
Control and monitoring Environment
- AVS-Monitor AVS-Monitor enables to remotely set, control and monitor an EtherSound network and provides enhanced control pages to manage the specific parameters of cards inserted in the different slots
