Description
The f9 is a professional pre-polarized condenser microphone used for stage and studio applications. The f9 is known for its clear, accurate response particularly in the upper frequency range. Ideally suited for a wide variety of acoustic instruments, the f9 is an excellent choice for cymbals, overhead, goodie table and ambient room miking.
Characterized with a uniformly controlled cardioid polar pattern, the f9 is designed to capture the acoustics of the instrument being miked while at the same time isolating it from the rest of the instruments on stage. The f9 features a 16 mm pre-polarized capsule with gold vapor diaphragm and a frequency response of 40 Hz – 20 kHz.
The f9 is easy to position, durable and manufactured with high standards and tight tolerances. The f9 includes a precision cast zinc alloy body, black coat finish, laser etched model and serial number, steel mesh grill, gold XLR connector and a tension-fit heavy duty nylon mic clip.
With its low impedance and balanced output, the f9 has interference-free performance. This mic operates on phantom power of 12-48 V.
Features
- Excellent multi-purpose instrument microphone
- Interchangeable threaded capsule
- Ideal for medium field (8-12 inches) or far field (12-24 inches)
- Cast zinc alloy housing
- Roadworthy construction
Applications
- Cymbals
- Overheads
- Hi-Hat
- Goodie table
- Audience mic
Supplied Accessories
- Mic stand adapter (DCLIP)
- Carrying pouch (P1)
Specifications
Transducer Type Pre-polarized condenser
Frequency Response 40 Hz - 20 kHz
Polar Pattern Cardioid
Output Impedance 200 ohms
Sensitivity 8 mV / Pa @ 1k
Capsule Technology Gold vapor diaphragm
Off Axis Rejection ≥24 dB
Noise Floor 22 dB (A weighted)
Signal to Noise Ratio 72 dB
Dynamic Range 115 dB
Maximum SPL ≥137 dB
Power Requirements 12-48 volts phantom
Connector 3 pin gold plated male XLR connector
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
Housing / Finish Cast zinc alloy / Black coat
Weight 91 g / 3.2 ounces
Length 111 mm / 4.37 inches
