Description
The f5 is an all purpose dynamic instrument microphone used for stage and studio applications. The f5 is able to handle sound pressure levels in excess of 137 dB without distortion and can be used to mic a wide variety of musical instruments, guitar and bass cabinets, vocals and speech.
The f5 is characterized with a hypercardioid pickup pattern for isolation and feedback control and is equipped with a LM™(Low Mass) diaphragm for natural, accurate sound reproduction.
The f5 is sturdy, compact and easy to position. With a wide frequency response of 55 Hz – 15 kHz, the f5 provides clear, accurate, natural sound reproduction without having to rely on EQ. The f5 includes a precision cast zinc alloy body, steel mesh grill, black coat finish, laser etched model and serial number, gold XLR connector and a heavy duty nylon mic clip.
Features
- Clear and accurate sound reproduction
- Handles high SPL without distortion
- Provides exceptional gain before feedback
- Provides excellent isolation on stage
- Precision cast zinc alloy body and grill
- 3 year warranty
Applications
- Live stage, studio
- Snare, toms, percussion
- Guitar cabinets, electric instruments
- Bass cabinets
- Brass, flute, woodwinds
- Acoustic instruments
- Vocals, speech
Supplied Accessories
- Heavy duty nylon mic clip (MC1)
- Carrying pouch (P1)
Specifications
Transducer Type Dynamic
Frequency Response 52 Hz - 15 kHz
Polar Pattern Hypercardioid
Output Impedance 580 ohms
Sensitivity 2.2 mV / Pa @ 1k
Capsule Technology LM Type A
Off Axis Rejection >20 dB
Maximum SPL ≥137 dB
Power Requirements None
Connector 3 pin gold plated male XLR connector
Polarity Positive voltage on pin 2 relative to pin 3 of output XLR connector
Housing / Finish Cast zinc alloy / Black coat
Weight 283 g / 10 ounces
Length 145 mm / 4.7 inches
