Audix A1127 Omnidirectional Metal Film Condenser Microphone

(No reviews yet) Write a Review
SKU:
A127
UPC:
687471241295
Weight:
0.50 LBS
Shipping:
Calculated at Checkout
  • Audix A1127 Omnidirectional Metal Film Condenser Microphone
  • Audix A1127 Omnidirectional Metal Film Condenser Microphone
  • Audix A1127 Omnidirectional Metal Film Condenser Microphone
  • Audix A1127 Omnidirectional Metal Film Condenser Microphone
  • Audix A1127 Omnidirectional Metal Film Condenser Microphone
$1,999.00

Description

A127

OMNIDIRECTIONAL METAL FILM CONDENSER MICROPHONE

The A127 is an omnidirectional metal film condenser microphone, designed to capture the most accurate and purest form of acoustic instruments and sound sources. The A127 delivers unmatched performance for recording, broadcast, film, and sound design.

  • Pre-polarized half-inch Type 1 metal film capsule (IEC 61094-4 compliant)
  • Omnidirectional polar pattern
  • Excellent clarity, detail, and transient response
  • Transformerless, low-noise circuitry
  • Active driven shield

A127 is an omnidirectional metal film condenser microphone, designed to capture the most accurate and purest form of acoustic instruments and sound sources. Fundamental to the A127 design is the low-noise Type 1 metal film capsule and precision-machined electro-mechanical components. The A127 delivers unmatched performance for recording, broadcast, film, and sound design.

With a frequency response of 10 Hz – 20 kHz and a wide dynamic range of 133 dB, the A127 excels in the most demanding applications. Capsule design features a precision-tuned 3-micron metal diaphragm, resulting in an exceptionally accurate and stable response with ultra-low self-noise of 7 dBA. The A127 circuit is designed and built to exacting specifications and is coupled to the capsule by a series of driven shields to protect the microphone from external interference and capacitance coupling. The mechanical components of the gold-plated shield and the corrosion-resistant housing are precision-machined by Audix in Wilsonville, Oregon.

ADVANTAGES OF THE HALF-INCH FILM CAPSULE

The A127 features a reference-grade capsule (Type 1 IEC 61094-4 compliant) with a precision-tensioned metal film diaphragm, providing consistent and reliable performance, even in the most demanding environments. The half-inch size of the diaphragm represents the “sweet spot” for acoustic sound capture, which is why it has become the standard for acoustic measurement. The ultrathin, 3-micron metal film diaphragm provides excellent transient response and a level of detail and realism simply not attainable with conventional diaphragm materials.

SUPPLIED ACCESSORIES

  • DCLIP(opens a new window) – Heavy-duty nylon molded snap-on clip
  • POUCHAXSM – Protective zippered carrying case
  • WS90 – Acoustical windscreen
View AllClose

Specifications

  • Transducer Type 1/2″ Type 1 metal film capsule (IEC 61094-4 compliant)
  • Frequency Response 10 Hz – 20 kHz
  • Polar Pattern Omnidirectional
  • Output Impedance 150 Ohms
  • Sensitivity 28 mV / Pa @ 1 kHz
  • Signal to Noise Ratio 82 dBA
  • Maximum SPL 140 dB SPL
  • THD + N .004% @ 94 dB SPL | 1.0% @ 140 dB SPL
  • Equivalent Noise Level 12 dBA
  • Dynamic Range 128 dB
  • Connector 3-pin XLR m
  • Power Requirements 48 V +/- 4 V Phantom
  • Power Consumption 3 mA
  • Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
  • Materials / Finish Brass / Black
  • Dimensions 19 mm x 122 mm
  • Weight 123 g
View AllClose
