Elation Netron RDM 10 Universal Dual Input RDM Splitter

(No reviews yet) Write a Review
SKU:
NRD101
UPC:
810008260654
Weight:
4.00 LBS
Shipping:
Calculated at Checkout
  • Elation Netron RDM 10 Universal Dual Input RDM Splitter
  • Elation Netron RDM 10 Universal Dual Input RDM Splitter
  • Elation Netron RDM 10 Universal Dual Input RDM Splitter
  • Elation Netron RDM 10 Universal Dual Input RDM Splitter
$796.00

Description

RDM 10

The Netron RDM 10 is a universal dual input RDM splitter with an advanced feature set to cover a wide variety of applications. Its combination of a high density ten-port AB splitter with a two port EtherDMX node, DMX cue recording plus contact closures for preset and cue recall make this a truly universal tool for installations and production environments.

Features

  • Key Features
  • 10 assignable DMX outputs
  • Integrated 2 Universe Artnet/sACN node
  • Configurable DMX refresh rate
  • Dual DMX Inputs for backup and signal loss options
  • Remote configuration via internal webpage
  • 1.8” OLED Display with rotary knob
  • 99 Internal cues with fade and delay time
  • Contact closures for cue or preset recall
  • Powder-coated aluminum rackmount housing
View AllClose

Specifications

Connections

  • Front
    • (2) 5pin DMX Input
    • (10) 5pin Opto-Isolated DMX Outputs
    • Full color OLED display
    • Encoder w. Push to Select / Exit Button
  • Back
    • (2) 5pin DMX Input (parallel with front)
    • (2) 5pin DMX Through
    • (2) Locking RJ45 Ethernet Network In
    • (10) Contact Closures (Terminal Block)
    • Locking Power In/Thru

Physical

  • Mounting: Rackmount
  • Length: 482.5 mm (19 in.)
  • Width: 146 mm (5.7 in.)
  • Height: 44 mm (1.7 in.)
  • Weight: 1.82 kg (4 lbs)

Electrical

  • 100-240 V nominal, 50/60 Hz
  • POE 802.3af

Included Items

  • 1.5m Locking power cable (EU or US version)
View AllClose
