Description
Powerful plug-on transmitter that turns every wired dynamic microphone into a wireless transmitter for evolution wireless G4 100P Series systems. For documentary, Mobile Journalism and audio for video applications.
Features
- Powerful camera receiver, easily mounted on any kind of microphone
- Excellent sound and construction quality
- Easy to use and fast setup time
- Powerful and reliable wireless transmission
- Range: up to 100 meters / 330 feet
- Up to 8 hours of operation time
What's in the box?
- SKP 100 G4 plug-on transmitter
- 2 AA batteries
- quick guide
- safety guide
- manufacturer declaration sheet
Specifications
- Frequency range
- A1: 470 - 516 MHz
- A: 516 - 558 MHz
- AS: 520 - 558 MHz
- GB: 606 - 648 MHz
- G: 566 - 608 MHz
- B: 626 - 668 MHz
- C: 734 - 776 MHz
- D: 780 - 822 MHz
- E: 823 - 865 MHz
- JB: 806 - 810 MHz
- K+: 925 - 937,5 MHz
- Dimensions Approx. 105 x 43 x 43 mm
- Compander Sennheiser HDX
- THD, total harmonic distortion ≤ 0.9 %
- Weight approx. 195 g
- Signal-to-noise ratio ≥ 110 dBA
- RF output power Max. 30 mW
- Switching bandwidth up to 42 MHz
- Peak deviation ±48 kHz
- Nominal deviation ±24 kHz
- Operating time Typically 8 h
- Modulation Wideband FM
- Power supply 2 AA batteries, 1.5 V or BA 2015 accupack
- Current consumption
- at nominal voltage: typ. 180 mA
- with transmitter switched off: ≤ 25 μA
- Input impedance 68 kΩ, unbalanced
- Max. Input voltage 3.3 Veff
- Powering 3 V battery / 2.4 V rechargeable battery
- Transmission frequency Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
- AF frequency response 80 – 18,000 Hz
- Temperature Range -10 °C to +55 °C
- Frequency stability ≤ ±15 ppm
