Specifications

Input Impedance
Mic Input - Selectable 450 ohms (Lo-Z) or 1.6 kilohms (Hi-Z)
DI Input - Selectable 2.2 megohms (Lo-Z) or 50 kilohms (Hi-Z)

Output Load Impedance
20 Hz to 20 kHz +/- 1 dB

Maximum Gain
61 dB

Tube Complement
(1) 12AX7, (1) 12AT7

Maximum Mic Input Level
-12 dBu, 1.0% THD+N Ratio

Maximum Instrument Input Level
+4 dBu, 1.0% THD+N Ratio

Maximum Gain Mic Input
55 dB (1.6K ohm input), 60 dB (450 ohm input)

Mic/Instrument In Frequency Response
20 Hz to 20 kHz, +/- 0.1 dB

Maximum Gain Instrument Input
37 dB

Dimensions
L: 14"
W: 5 3/4"
H: 5"

Weight
9 lbs.

Vendors Other Products

Universal Audio Solo/610 Classic Tube Single Channel Mic Pre/DI

Price:
$999.00
SKU:
S610D
Weight:
12.30 LBS
Availability:
Usually ships within 24 hours
Shipping:
Calculated at checkout


Product Description

The All-Tube 610 Console Mic Preamp Sound in a Rugged “Go Anywhere” Design

The SOLO/610 delivers the classic Putnam 610 tube console sound in a rugged, highly versatile mic preamp design. This unit provides the silky, vintage warmth of the original console’s mic amp design, and will flatter any microphone or instrument with its signature sound. Thanks to its convenient form factor, the SOLO/610 can be conveniently used in the control room or the recording room, on stage, or on a desktop. Functionally lean but sonically mean, the SOLO/610 maintains the character of the 610 console — at a price every serious project studio can afford.

The SOLO/610 offers Mic and DI inputs, and features Gain and Level control for a wide variety of clean to colored tones. Unlike its predecessors, the SOLO/610 has continuous Gain control with even greater range, allowing for more precise gain structuring — doubling as input signal padding. The SOLO/610 has all the essential features like 48v Phantom Power, Lo-Cut filtering, Phase Reverse and flexible dual impedance selection for both Mic and DI inputs. The SOLO/610 includes essential DI features like Thru use in conjunction with an amplifier, plus Ground Lift and a versatile Mic/Line level output switch.

Features

  • Classic Putnam 610 console mic preamplifier and DI
  • Legendary all-tube sound, at a project studio price
  • Gain, Level, and Impedance selection for maximum tonal variety
  • Portable design for studio, desktop or stage
  • Rugged construction-steel chassis
  • DI features include Thru and Mic/Line level output
  • Hand-built in USA; backed by 1-year limited warranty
