Description
The durable BLX1 features a lightweight, ergonomic design and adjustable gain control. For use with BLX® Wireless Systems.
Features
- Quick and easy receiver frequency matching
- TQG connection for use with Shure lavalier, headset, earset and instrument microphones and guitar cables
- Easily accessible On / Off switch
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
Specifications
- Working Range: 91 m (300 ft) Line of Sight
- Note: Actual range depends on RF signal absorption, reflection and interference.
- Audio Frequency Response: 50 to 15,000 Hz
- Note: Dependent on microphone type
- Total Harmonic Distortion
Ref. ±33 kHz deviation with 1 kHz tone - 0.5%, typical
- Dynamic Range: 100 dB, A-weighted, typical
- Operating Temperature: -18°C (0°F) to 57°C (135°F)
- Note: Battery characteristics may limit this range.
- Polarity: Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low-impedance output) and the tip of the high impedance 1/4-inch output.
- Audio Input Level
- gain max -16 dBV maximum
- min (0 dB) +10 dBV maximum
- Gain Adjustment Range: 26 dB
- Input Impedance: 1 MΩ
- RF Transmitter Output: 10 mW, typical, varies by region
- Dimensions: 110 mm X 64 mm X 21 mm H x W x D
- Weight: 75 g (2.6 oz.), without batteries
- Housing: Molded ABS
- Power Requirements: 2 LR6 AA batteries, 1.5 V, alkaline
- Battery Life: up to 14 hours (alkaline)
