Mojave MA-50 Large Diaphragm Transformerless Solid State Condenser

(No reviews yet) Write a Review
SKU:
MA-50BK
UPC:
899060002761
Weight:
6.00 LBS
Shipping:
Calculated at Checkout
Availability:
Usually ships within 24 hours.
  • Mojave MA-50 Large Diaphragm Transformerless Solid State Condenser
  • Mojave MA-50 - Back
  • Mojave MA-50 Large Diaphragm Transformerless Solid State Condenser
$599.00

Description

MA-50 Large-diaphragm Transformerless Condenser Microphone

The challenge? Create a transformerless microphone circuit without the inherent problems found in transformerless microphones. Technical Grammy® award winning microphone designer David Royer has created a thoroughly modern microphone that rises to that challenge: the new MA-50. Designed to produce the clarity and realism that Mojave microphones are known for – at an entry level price - the MA-50 out performs well-known transformerless mics costing many times more.
The MA-50 is the perfect microphone for pros and semi-pros alike. Utilizing the same capsule as the MA-200 and MA-201fet, it handles the fastest transients with ease – even up to 140 dB.

Features

• Large-diaphragm cardioid 3-micron capsule
• Fixed-cardioid polar pattern
• Transformerless circuitry
• Very low noise
• Includes professional shock mount
• Simple – yet elegant design - perfect for home recording
• High SPL handling
• Fast transient response

Recommended Applications

• Vocals
• Voice-over
• Acoustic Instruments
• Drum Overheads
• Percussion Instruments
• Foley/ADR

View AllClose

Specifications

  • TRANSDUCER TYPE: Externally polarized pressure gradient capacitor
  • DIAPHRAGM: 1-inch diameter, gold sputtered
  • DIAPHRAGM THICKNESS: 3-microns
  • POLAR PATTERN: Cardioid
  • FREQUENCY RESPONSE: 20 Hz- 20 kHz, + 3 dB
  • SENSITIVITY: -40 dB re. 1V/pa
  • MAXIMUM SPL: 125 dB
  • DISTORTION: <0.5% @140 dB SPL
  • SELF NOISE: Better than 16 dB (A weighted)
  • IMPEDANCE: <100 ohms
  • RECOMMENDED LOAD: 1500 ohms or higher
  • POWERING: 48VDC phantom power; current 2 mA.
  • DIMENSIONS AND WEIGHT:
    • Carrying case with microphone, shock mount: 10” x 9” x 4.5”, 4 lbs.
    • Microphone: 7 5/8” X 2” (194mm x 51mm), 1 lb. (0.45Kg
View AllClose
