Audient ASP4816 Analog In-line Recording Console

(No reviews yet) Write a Review
SKU:
ASP4816SE
Weight:
199.00 LBS
Shipping:
$750.00 (Fixed Shipping Cost)
Availability:
Special order. See additional notes.
  • Audient ASP4816 Analog In-line Recording Console
  • Audient ASP4816 Analog In-line Recording Console
  • Audient ASP4816 Analog In-line Recording Console
  • Audient ASP4816 Analog In-line Recording Console
  • Audient ASP4816 Analog In-line Recording Console
$16,999.00

Description

ASP4816 is a small format analogue console from legendary designer David Dearden. Building on the success of its bigger brother the ASP8024-HE, the ASP4816 delivers incredible functionality in a smaller footprint, perfectly suited for both professional and project studios alike. Providing a versatile array of connectivity, signal conditioning, routing, summing, processing and monitoring capability the ASP4816 will quickly adapt to become the centre of your creative workflow.

Features at a glance

  • 48 Inputs
  • 16 Audient Mic Pres
  • 4 Band Splitable EQ
  • Mix Bus Compressor
  • 16 Record Buses
  • 8 Subgroups/Inserts
  • 6 Auxes , 2 Cue Sends
  • Inline Architecture
  • 4 Stereo Monitor Outputs
  • Comprehensive Monitor Control

BIG SOUND, SMALL FOOTPRINT

How will you mix it up?

WORLD CLASS MIC PRES

The professional sound you deserve.

We are the only company that use the same Class-A mic pre design throughout our entire product range, whether you’re in the studio with the ASP4816 or on the road with iD14, you’re always guaranteed the same world class Audient sound.

FOUR BAND EQ

Flexible, powerful, musical

The incredibly flexible, Dearden designed EQ offers two fully parametric bands that span from 40Hz to 20kHz, offering a powerful and punchy sound. These are flanked by low and high shelving EQ bands (with a minimal signal path) that are perfect for adding weight and air to your source and when combined with the parametric EQ, make for the ultimate sculpting tool. Don’t forget, you can really take advantage of the EQ as it can be split across both the short and long faders, making us one of the only companies to offer this unique feature.

THE MIX BUS COMPRESSOR

Make light work of your mixes

Based on technology from the 80s and 90s the ASP4816’s mix bus compressor is known for adding a rock and roll dynamic to your mix. Often likened to classic analogue boards, the ASP4816’s mix bus compressor provides that classic VCA ‘glue’ that will give your mix that ‘sounds like a record’ feeling.

COMPREHENSIVE MONITOR CONTROL

The complete monitoring solution

Our fully featured monitor control section offers full artist communication, talkback control, powerful source selection and loud speaker control with a short passive signal path for incredibly clear and accurate monitoring.

COMPLETE CONNECTIVITY

The heart of your studio

With an impressive array of connectivity options the ASP4816 offers the versatility of a large format console in a smaller footprint. Whether you're bringing in your D/A outputs, effects returns and other line sources, or using the buses to record 16 channels of audio straight into your DAW via your converters or as 16 additional FX sends or parallel feeds, the ASP4816 provides ultimate flexibility for the modern studio.

HOW DOES IT SOUND?

Accurate translation of your source

We asked signed singer songwriter Lizzy McAvoy to give a demo on recording drums using the ASP4816, which is at the heart of her studio in the musical hub of Nashville. Lizzy shows just how good a drum sound you can get using just the console's mic pres, EQ and compressor. Hear the results for yourself...

INLINE ARCHITECTURE

Refine your workflow.

The consoles inline architecture allows you to start building your mix as your tracking. By using the long and short faders you can create separate record and monitor balances on one channel strip, all while being able access the consoles splitable EQ and aux sends, perfect for getting it right from the start. Experience the classic large format console workflow in a smaller footprint and take your mixes to the next level.

POWER CONSUMPTION

No external power source required

ASP4816's clever design allows it to be plugged directly into the wall and has no need for a noisy external power source, allowing it to be installed quickly into any studio and making the ASP4816 one of the most efficient small format recording consoles on the market.

ERGONOMIC DESIGN

The large format sound in a small footprint

After years of listening to what our customers want in a small format recording console and through clever circuit board design the ASP4816 provides you with the versatility and sound of a large format recording console but in a small and affordable package. Making it the perfect analogue console solution for even the smallest of studios.

EFFORTLESS 5.1 SURROUND SOUND MIXING

ASP510 integration available on all ASP4816s

Whether you’re working on film scores or simply mixing in 5.1, the ASP510 surround sound monitor controller will integrate seamlessly with your ASP4816, providing you with an efficient, powerful and intuitive 5.1 surround sound workstation. All whilst using only one connection.

View AllClose

Specifications

Frequency Response

Mic input to Mix output: <+0,-0.3dB 20Hz-20kHz @6-40dB gain.
Line input to Mix output: <+0,-0.3dB 20Hz-20kHz @0dB gain.

THD AND NOISE AT +20dB OUTPUT

Mic XLR input to any output: <0.005% at 1kHz
Line input to any output: <0.005% at 1kHz
Tape input to any output: < 0.003% at 1kHz

NOISE

Mic EIN (20-20kHz, 150R source): <-127.5dBu
Bus noise (no inputs routed): <-93dBu
Bus noise (36 inputs routed): <-78dBu

CROSSTALK AND MUTE ATTENUATION AT 1kHz

Short fader Mute: >90dB
Long fader Mute: >90dB
Mix assign: >90dB
Bus assign: >90dB

MIC CMRR

70dB (Min gain)
75dB (Max gain)

MAXIMUM INPUT

Mic: >+21dBu (min gain)
Line: +30dBu (min gain)
insert return: >+21dBu

MAXIMUM OUTPUT INTO 2K OHMS

Mix output: >+26dBu
Bus output: >+26dBu
Aux output: >+26dBu
Insert send: >+20dBu
Monitor, Studio, F/B outputs: >+20dBu
